R134A Compressor Cooling
1. Cook and Cold type is available
2. Adopt the material met food safety requirement, hygienic and safe
3. Both hot and cold tanks are made of high quality SS304 stainless steel
4. Regular hot tank size 1.2 liter, cold tank size 3.8 liter (hot and cold tank size can be made as per customer’s special request)
5. Inside heater or outside heater or re-heating function is optional

Technical Parameters

Model	YLR2-5-X(20T)	YLR2-5-X(20T-G)
AC Voltage	220V/50HZ or 110V/60HZ	220V/50HZ or 110V/60HZ
Cooling Power(W)	112	112
Heating Power(W)	500	500
Cooling Capacity(L/H)	≤10℃ 2L/H	≤10℃ 2L/H
Heating Capacity(L/H)	≥90℃ 5L/H	≥90℃ 5L/H
Energy Consumption	1.65kW.h/24h	1.65kW.h/24h
Working Ambient	10-38℃	10-38℃
Electric Shock Protection Type	I	I
N.W.(KGS)	11.5	11.5
G.W.(KGS)	12.5	12.5
Unit Meas.(MM)	310×310×510	310×310×510
Regular Packing Meas.(MM)	360×390×560	360×390×560
Simple Packing Meas.(MM)	330×360×550	330×360×550
