R134A Compressor Cooling
1. Cook type and cold type are available
2. Raw materials comply with food safety requirements, hygienic and safe
3. Both hot and cold tanks are produced from high quality SS304 stainless steel
4. Hot tank provides a capacity of 1.2 liters while cold tank 3.8 liters. (Customized tank is available)
5. Inside heater, outside heater and heater with a reheat system are optional.

Technical Parameters of Hot and Cold Water Dispenser

Model	YLR2-5-X(280L)	YLR2-5-X(280L-C)	YLR2-5-X(280L-B)	YLR2-5-X(280L-G)	YLR2-5-X(280L-CG)	YLR2-5-X(280L-BG)	YLR2-5-X(280L-XGJ)
Heating Power(W)	500	500	500	500	500	500	500
Cooling Capacity(L/H)	≤10℃ 2L/H	≤10℃ 2L/H	≤10℃ 2L/H	≤10℃ 2L/H	≤10℃ 2L/H	≤10℃ 2L/H	≤10℃ 2L/H
Heating Capacity(L/H)	≥90℃ 5L/H	≥90℃ 5L/H	≥90℃ 5L/H	≥90℃ 5L/H	≥90℃ 5L/H	≥90℃ 5L/H	≥90℃ 5L/H
Energy Consumption	1.65kW.h/24h	1.65kW.h/24h	1.65kW.h/24h	1.65kW.h/24h	1.65kW.h/24h	1.65kW.h/24h	1.65kW.h/24h
Ambient Temperature	10-38℃	10-38℃	10-38℃	10-38℃	10-38℃	10-38℃	10-38℃
Electric Shock Protection Degree	I	I	I	I	I	I	I
N.W. (KGS)	16.5	17	18	16.5	17	18	18
G.W. (KGS)	18	18	19.5	18	18	19.5	19.5
Unit Meas.(MM)	340×350×990	340×350×990	340×350×990	340×350×990	340×350×990	340×350×990	340×350×990
Simple Packing Meas.(MM)	350×370×1060	350×370×1060	350×380×1060	350×370×1060	350×370×1060	350×380×1060	350×370×1060
